介質(zhì)高反鏡
Dielectric (HR) Mirrors have the advantage of high reflectance and superior surface quality and accuracy. They offer near total reflection, minimizing losses in nearly all optical systems. These coatings are very durable, easily cleaned, and resistant to laser damage and reflectance can be more than 99%. The wavelength (range) of reflectance depends on incident angles (0 degree or 45 degree).
Specifications
|
Item
|
Commercial
|
High Precision
|
|
Material:
|
Fused Silica; N-BK7 or others
|
|
|
Dimension X×Y(φ):
|
1×1mm~25.4×25.4mm；φ3~φ25.4mm
|
|
|
Dimension tolerance:
|
±0.1mm
|
±0.03mm
|
|
Parallelism:
|
＜3′
|
＜30″
|
|
Clear aperture:
|
85%
|
|
|
Surface quality:
|
MIL20-10
|
|
|
Flatness(per 25.4mm):
|
λ/2@ 632.8nm
|
λ/10@ 632.8nm
|
|
Coating:
|
Specified by customer(Single wavelength HR＞99.8% per surface)
|
|
