摻釹釩酸釔（Nd: YVO4）
It is the most efficient laser host crystal for diode pumping for diode laser-pumped solid-state lasers of low or middle power density currently. With our strict control from raw materials and growing process, our Nd:YVO4 is featured with low lasing wavelength absorption, high slope efficiency and single-mode output. They are applied in diode pumped solid state laser with wavelength at 1064nm,1342nm,914nm,then frequency doubling to 532nm(green), 671nm(red), 457nm(blue).They are the ideal laser tools for light projection, medical diagnostics, laser printing, spectroscopy, semiconductor and biology instruments etc.
Specifications
|
Item
|
Specifications
|
|
Nd:dopant level:
|
0.3atm%~3.0atm%
|
|
Dimension X×Y×Z:
|
3×3×0.5mm;3×3×1mm;3×3×3mm；
|
|
Dimension tolerance:
|
±0.1mm
|
|
Parallelism:
|
≤10″
|
|
OA.Orientation tolerance:
|
±0.5°
|
|
Clear Aperture:
|
90%
|
|
Surface Quality:
|
MIL20-10
|
|
Insertion loss:
|
0.1DB
|
|
TWF distortion:
|
λ/8@ 632.8nm
|
